HE32-D

1. Rod type fixation, strong load capacity for vertical use.
2. High load, high precision, precise positioning, using precision screw drive.
3. Compact structure, with three NSK bearing designs on the base, high guidance accuracy, and built-in dual 15mm guides to prevent rotation.
4. Using aluminum alloy cylinder, the entire series is equipped with induction magnets, and multiple sensors can be configured.
5. The front cover is equipped with a dust ring and a thick oil-free graphite copper sleeve is built in.
6. Multiple domestic or imported AC AC (DC) servo motors or stepper motors can be selected for driving.
7. It can meet customer customization needs, customize non-standard products, and can be equipped with grating rulers and pressure sensors.
